Machine functions:
Pre-milling, gluing, end trimming, rough trimming, fine trimming, corner trimming, scraping, buffing.
Technical Specifications:
Model REX-E450A, REX-E450C, REX-E450D
Banding tape thickness 0.4-3mm
Banding tape width 12-65mm
Workpiece thickness 10-60mm
Workpiece length ≥100mm
Workpiece width ≥50mm
Heating power 1.8kw
Feeding motor power 3.7kw
Pre-milling motor power 2.2kw*2
Glue spreading motor power 0.75kw
End trimming motor power 0.5kw*2
Rough trimming motor power 0.75kw*2
Fine trimming motor power 0.75kw*2
Corner rounding motor power 0.5kw*2
Polishing motor power 0.37kw*2
Feeding speed 10-23m/min
Air pressure 0.8Mpa
Net weight 2800kg
Machine size 6700*850*1520mm
Gross weight 2950KG
Packing size 6730*880*1580mm
Industrial Grade Edgebanders
REX-E450D
Starting at $39,950
6 Function Edgebander
1. Gluing
2. End trimming
3. Rough trimming
4. Fine trimming
5. Buffing
6. Scraping
REX-E450C
Starting at $49,950
7 Function Edgebander
1. Gluing
2. End trimming
3. Rough trimming
4. Fine trimming
5. Buffing
6. Scraping
7. Corner trimming
REX-E450A
Starting at $55,950
8 Function Edgebander
1. Gluing
2. End trimming
3. Rough trimming
4. Fine trimming
5. Buffing
6. Scraping
7. Corner trimming
8. Pre-milling
